Workflow States

Workflow states tell you where a workflow has got to and whether anything is still waiting for someone. A workflow has a status, such as IN PROGRESS or COMPLETED, and each of its action requests shows whether it is still waiting for a reply, is overdue, or has been answered. Use them to see at a glance what still needs your reply, which work is late, and which workflows have finished.

Understanding workflow stages and states in Docwize

What this page covers​

  • Where you see workflow states
  • The status of a workflow: In Progress, Completed and Cancelled
  • The state of an action request: waiting for a reply, overdue, replied and not answered
  • How a workflow moves from one state to the next
  • Which names are the same everywhere, and which your administrator sets up

Where you see workflow states​

You see workflow states in the Inbox. When you open a workflow there:

  • the header at the top shows the workflow's status, next to its subject, who started it and when;
  • each action request on the User Tasks tab has a card that shows where its reply stands.

The Inbox list can also be sorted so that Overdue or Completed workflows come first. See Left Sidebar.

Workflow status​

The status in the workflow header sums up the whole workflow.

StatusColourWhat it means
IN PROGRESSAmberAt least one action request is still waiting for a reply.
COMPLETEDGreenEvery action request has a reply and the workflow has finished.
CANCELLEDRedThe workflow was cancelled before it finished.

In Progress​

A workflow is IN PROGRESS from the moment it is sent until it finishes. Its open action requests wait for a reply, each with an orange Complete button for the person it is waiting for.

A workflow with the status IN PROGRESS in its header, and a DOCS INBOX REVIEW action request card that says Waiting for a reply (3 days left), with CompleteA workflow in progress

Completed​

A workflow is COMPLETED when every action request has a reply and the workflow has run its last step. Each card shows Replied with the reply that was given, and any note. The card's button changes to View, because there is nothing left to answer.

A workflow with the status COMPLETED in its header, and an action request card that says Replied Reviewed, with the note Checked against the maintenance schedule and a View buttonA completed workflow

Cancelled​

A workflow is CANCELLED when it has been stopped before it finished. A red banner says This workflow has been cancelled, and the workflow is kept for reference only. An action request that had no reply says Not answered, its due date no longer counts down, and its button changes to Preview, so you can still look at it but can no longer reply.

A cancelled workflow: the status CANCELLED in the header, the banner This workflow has been cancelled, and an action request card that says Not answered, with PreviewA cancelled workflow

Action request states​

Each action request card reads as a short thread: who sent the request and to whom, then where the reply stands. The second line of the thread shows the state.

What the card showsWhat it means
Waiting for a reply, with the days left, for example (3 days left)Nobody has replied yet, and the due date has not passed.
Waiting for a reply, with the days overdue in red, for example (2 days overdue)Nobody has replied yet, and the due date has passed.
Replied, with the reply, for example Replied ReviewedSomeone has replied. Their note, if they left one, is shown under the reply.
Not answeredThe workflow was cancelled before anyone replied.

Overdue action requests​

An action request is overdue when its due date has passed and nobody has replied. The workflow stays IN PROGRESS, and the card counts the days since the due date in red. The card keeps its Complete button, so the request can still be answered like any other open request.

A workflow IN PROGRESS with an action request card due 10 Nov that says Waiting for a reply (2 days overdue) in red, with CompleteAn overdue action request

How a workflow moves between states​

  1. When a workflow is sent, it is IN PROGRESS, and its first action requests are Waiting for a reply.
  2. If a due date passes before anyone replies, the request is overdue, and the workflow is still IN PROGRESS.
  3. Each reply is shown on its card as Replied, and decides what happens next: another action request, a step the workflow runs by itself, or the end of the workflow. See Completing Action Requests.
  4. When nothing is left to answer and the workflow has run its last step, it is COMPLETED.
  5. If the workflow is cancelled before that, it is CANCELLED, and any request still open is Not answered.

What is the same everywhere, and what your administrator sets up​

The workflow statuses (IN PROGRESS, COMPLETED, CANCELLED) and the states on an action request card are the same in every Docwize workspace.

The names of action requests and of their replies are set up by your administrator, so they differ from one workspace to another. In the pictures on this page, DOCS INBOX REVIEW is the action request and Reviewed is its reply. Your administrator also decides which steps a workflow has, who each action request goes to, and when it is due.

For administrator setup, see:
